StarTech.com 2-Port USB/HDMI KVM Switch with Audio and USB 2.0 Hub SV231HDMIUA

Share a keyboard, mouse and HDMI monitor between 2 multimedia computers

The SV231HDMIUA 2-port USB HDMI KVM Switch lets you control two USB-enabled multimedia computers or devices with HDMI video interfaces, using a single peripheral set/console (USB keyboard, mouse, monitor, speakers and microphone).

A highly versatile KVM solution, the USB HDMI KVM Switch features an integrated 2-port USB 2.0 hub that lets selected computers access shared high speed USB devices, eliminating the cost of duplicate USB peripheral purchases.

Ensuring high quality video capability, the HDMI KVM switch supports HD resolutions of up to 1920 x 1200. Offering genuine digital signal transmission over the cable, this switch can be used to share one HD panel between multiple HDMI sources such as Blu-Ray players, Video Game consoles and HD media centers.

The switch also supports audio and microphone switching functions and allows you to select connected computers, USB device hub ports and audio/mic channels either simultaneously or independently using either front-panel push-buttons or keyboard hotkeys.

Backed by a StarTech.com 3-year warranty and free lifetime technical support.

The StarTech.com Advantage

- Eliminate duplicate display expense by sharing one set of peripherals and a single Display or TV between a Game console (Xbox360 or Playstation PS3) and PC
- Versatile audio support for both HDMI audio and 3.5mm analog audio
- Integrated USB 2.0 hub and Mic/Audio ports allow the user to have full multimedia control of two computers and share USB peripherals eliminating the expense of duplicate devices

Features


Audible tone to indicate PC switching


Independent Audio and USB 2.0 hub switching


Manual video adjustments via rear func button


No software drivers required; OS independent


Share four USB peripherals between two PCs; Keyboard, Mouse, and two other USB Devices


Supports High Resolutions Digital video up to UXGA (1600x1200), WUXGA (1920x1200), and 1080p (1920x1080)


Supports Plug&Play operation


Supports push button and hotkey PC Switching


User-defined scan time intervals



Design


Mean time between failures (MTBF)

126813 h


Product colour

Black


Rack mounting

No


Certification

R0HS



Weight & dimensions


Height

40 mm


Width

125 mm


Depth

70 mm


Weight

634 g



Packaging content


Rubber feet

Yes


Manual

Yes


AC adapter included

Yes



Logistics data


Harmonized System (HS) code

85176200



Other features


Ports quantity

2


I/O ports

1x HDMI (F) 4x USB A (F) 6x 3.5mm (F) 2x USB B (F) 2x mini-HDMI (F)


Connectivity technology

Wired


Dimensions (WxDxH)

124.8 x 70 x 40 mm


Power requirements

AC 110 - 240 V



Operational conditions


Operating temperature (T-T)

0 - 40 �C


Operating relative humidity (H-H)

0 - 80


Storage temperature (T-T)

-20 - 60 �C



Ports & interfaces


Number of computers controlled

2


Keyboard port type

USB


Headphone outputs

3


Number of microphone inputs

3


Console ports

3.5mm headphone, 3.5mm mic, HDMI, USB A


Mouse port type

USB


Video port type

HDMI


Console USB ports quantity

4



Performance


Maximum resolution

1920 x 1200 pixels


HD type

Full HD


Daisy chain

No



Power


AC input voltage

100 - 240 V


Power consumption (typical)

18 W


Power plug type

Type M


Input current

0.8 A


DC input voltage

12 V


Output current

1.5 A



Display


On Screen Display (OSD)

No



Packaging data


Package height

100 mm


Package depth

250 mm


Package width

188 mm


Package weight

1.1 kg
