StarTech.com 30ft 10m HDMI 2.0 Cable - 4K 60Hz Active HDMI Cable - CL2 Rated for HD2MM10MA

Create feature-rich HDMI connections, up to 10 m away with no signal lossThis CL2 HDMI cable is rated for in-wall installations. It also has a built-in active signal booster that allows for a connection distance of up to 30 feet (10 m) between your HDMI devices, with no signal loss. The cable is also backward compatible with previous HDMI specifications and will work with all of your existing HDMI devices.Create 4K HDMI connections over longer distancesThe cable's built-in amplifier circuitry actively boosts the HDMI signal with no external power required. It supports longer connections than regular HDMI. The active cable also features a thinner wire construction for more flexibility, making it ideal for in-wall installations.Experience the best that HDMI has to offerThis 4K HDMI cable supports resolutions of up to 4K@60Hz (3840x2160p) and bandwidths of up to 18Gbps. It also supports HDR (High Dynamic Range) for higher contrast ratio and vivid colors.With higher resolutions, increased speeds, and sharper images, the cable provides the very best HDMI capabilities available today. It's the perfect cable for creating the ultimate home-theater experience, for providing lifelike digital signage, or for delivering exceptional presentations.The cable also supports up to 32 uncompressed digital audio channels to provide crystal-clear sound.The HD2MM10MA is backed by a StarTech.com 2-year Warranty.Note : This cable features unidirectional architecture which requires that the cable is installed in the correct direction. Please ensure that the HDMI connector labelled with "TV" is connected to the display, in order to ensure that the device and the HDMI source are connected properly.The StarTech.com Advantage

Features


4K HDMI CABLE: Ultra HD HDMI 2.0 cable w/18Gbps bandwidth; 4K 60Hz UHD (3840x2160), HDR for high contrast ratio, 21:9 cinema aspect ratio, 32 audio channels at 1536Hz sampling rate & 3D video support


ACTIVE CIRCUITRY: Active bus powered amplifier boosts video up to 30ft/10m (no power supply needed), supports BT.2020 colorimetry & multi-stream audio to up to 4 users; performs to full HDMI 2.0 specs


DURABLE CABLE: Ideal for in-wall installations where CL2 rating required; Flexible PVC jacket; Al-Mylar Foil shield & gold plated connectors w/metal shell improve signal integrity & block external EMI


APPLICATIONS: Long high speed HDMI cable for use in home/offices/boardrooms/conference rooms/classrooms, works w/ your laptop for presentations via 4K monitors, projectors or displays w/CEC functions


SPECS: 30' (10m) / Black / HDMI 2.0 / HDMI Cord Male to Male / Jacket: PVC / Al-Mylar EMI Shielding / CL2 Fire Rated / 2-Year Warranty / Note: HDMI connector labelled "TV" connects to the display side



Weight & dimensions


Package height

38 mm


Package depth

315 mm


Package width

286 mm


Package weight

1 kg


Weight

1 kg



Logistics data


Master (outer) case width

305 mm


Master (outer) case height

265 mm


Products per master (outer) case

7 pc(s)


Harmonized System (HS) code

84733080


Master (outer) case length

345 mm



Technical details


Sustainability certificates

CE, RoHS



Features


Quantity per pack

1 pc(s)


Supported graphics resolutions

3840 x 2160


Maximum refresh rate

60 Hz


Cable length

10 m


Product colour

Black


High Dynamic Range (HDR) supported

Yes


Cable jacket material

Polyvinyl chloride (PVC)


Connector 2

HDMI Type A (Standard)


Connector 1

HDMI Type A (Standard)


Connector 1 gender

Male


Connector 2 gender

Male


Connector contacts plating

Gold


AWG wire size

24


Cable shielding

Aluminum mylar foil


Connector 1 form factor

Straight


3D

Yes


Cable rating

CL2


Connector 2 form factor

Straight


Bandwidth

18000 MB/s


HDMI version

2.0


Plug and Play

Yes
