StarTech.com 5.25 " Tray-Less Hot Swap Mobile Rack for 3.5 " Hard Drive HSB100SATBK

Hot-swap any 3.5in SATA hard drive easily from any computer with a 5.25in bay

This 3.5in SATA hard drive hot-swap bay allows you to install a 3.5in SATA drive in an available/unused 5.25in drive bay. To remove the drive, it's as simple as opening the front panel door; to re-insert a drive, simply insert the drive (connector first) until the door closes.

The hot swap bay offers a trayless design that makes it the ideal solution for quick and easy drive removals and insertions as part of a system building process, or integration into rackmount systems or industrial environments.

To maximize performance and utilize the full speed potential of your SATA III hard drives, this HDD Backplane supports SATA III for transfer speeds up to 6 Gbps when paired with a compatible controller.

Also a perfect addition for operating system image deployment and any task that requires being able to quickly access large volumes of data on the fly, the hot swap bay provides everything you need to expedite important projects while maintaining a reliable storage solution.

With support for SATA HDD speeds up to 6.0 Gbps, the mobile rack/backplane is fully compatible with RAID installations to ensure maximum performance and versatility for enhanced storage applications.

Designed to provide a durable and reliable operating experience, the mobile rack features a 50,000+ insertion rating and is backed by StarTech.com's 2-year warranty.

The StarTech.com Advantage

- Maximize performance, with file transfer speeds up to 6Gbps when paired with SATA III HDD and controller
- Quickly and easily install or remove hard drives without having to open the chassis with the innovative trayless design
- Rubber shock absorbers, a solid aluminum construction and 50,000+ insertion rating ensures longevity from both the drives and bay

Features


Holds a 3.5 SATA drive in a front accessible 5.25 bay


Trayless design: drives are not mounted into separate trays/enclosures


Lockable drive bay


Internal rubber shock absorbers


50,000+ insertion rating


Power and Activity LED indicator


Fully supports SATA revision 1/2/3 (1.5/3.0/6.0 Gbps) drives and controllers


Supports 3.5 inch form factor SATA hard drives


Plug-and-Play and Hot-Swap compatible


Add additional hot-swap bays to a server or workstation computer



Weight & dimensions


Height

42 mm


Width

149 mm


Depth

184 mm


Weight

261 g



Packaging content


Number of lock keys included

2 pc(s)


Manual

Yes


Screws included

Yes



Logistics data


Harmonized System (HS) code

84733080



Sustainability


Sustainability certificates

RoHS



Features


Number of cycles

50000


Key lock

Yes


Type

Bezel panel


HDD size

3.5"


Product colour

Black


Size (imperial)

13.3 cm (5.25")


Material

Aluminium, PU plastic


HDD interface

Serial ATA, Serial ATA II, Serial ATA III


Number of HDDs supported

1


Certification

CE, FCC, REACH


LED indicators

Activity, Power



Operational conditions


Operating temperature (T-T)

0 - 50 �C


Operating relative humidity (H-H)

5 - 85


Storage relative humidity (H-H)

5 - 95



Packaging data


Package height

51 mm


Package depth

159 mm


Package width

206 mm


Package weight

366 g
