Startech.Com
StarTech.com DK30C2DPPDUE Usb-C & Usb-A Dock - Hybrid DK30C2DPPDUE
- UPC:
- 0000000000000
- MPN:
- DK30C2DPPDUE
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Dual 4K60 | DisplayPort and/or HDMI | USB-IF Certified | 3x USB-A | 1x USB-C | Mac, Windows� & ChromeOS� | Lock SlotCreate a dual-4K 60Hz workstation with this certified universal laptop docking station for USB-C and USB-A laptops. The USB-C dock features 60W Power Delivery 3.0, dual HDMI and/or DisplayPort monitors, fast-charge, and both USB-C and USB-A peripheral ports.The Uniquely Universal Host CableThe USB-C dock comes with a universal host cable that is designed with an attached USB-C to USB-A adapter to accommodate USB-A laptops. The cable also features an extended length of 1 meter (3.3 ft.) to support a wide variety of workstation setups. Replacement host cables or extra host cables can be purchased separately here.Flexible Monitor ConnectionsThis is a dual 4K60Hz video docking station with support for both Ultra HD DisplayPort and/or HDMI monitors that lets you configure your video connections to best suit your needs.�Dual 4K DisplayPort | Up to 4096 x 2160p @ 60Hz�Dual 4K HDMI | Up to 4096 x 2160p @ 60Hz�Single 4K DisplayPort + Single 4K HDMI | Up to 4096 x 2160p @ 60Hz�Single 5K DisplayPort * | Up to 5120 � 2880*Requires monitor support for 5K using two DP portsCertified for Universal Compatibility & ReliabilityThis docking station is fully certified to meet top industry standards for USB-IF (USB 3.1 Gen 1, USB Type-C and Power Delivery), VESA DisplayPort and DisplayLink (video connections) certification to guarantee the highest quality, reliability, and compatibility.60W Power DeliveryUsing a single cable, the dock powers and charges your laptop as you work with 60W PD for faster charging, using the 135W power adapter.Easy and Convenient SetupFor fast setup right out of the box, the combo cable (USB-C with attached USB-A adapter) lets you connect any laptop. The dock has mounting holes for workstation mounting (bracket not included).The Connections You NeedConnect your devices with four USB 3.1 ports: 1x USB-C and 3x USB-A. Fast-charge your USB-C or USB-A smartphone. The dock provides a GbE port (PXE Boot support & Wake-on-LAN) and 3.5 mm 4-position headset audio jack. It also includes a security lock slot (K-slot) to protect against theft.For more installation flexibility, you can use StarTech.com mounting brackets (SSPMSUDWM& SSPMSVESA) that are specifically designed for our docks and hubs, to mount your dock to a desk, wall, or other surfaces to give you the customized setup you need.Enhance Productivity and Device Management with the StarTech.com Connectivity Tools ApplicationDeveloped to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:�Advanced Windows Layout Utility : To setup and save custom windows layouts.�Mac Address Pass-Through Utility : To improve network security.�USB Event Monitoring Utility : To track and log connected USB devices�Wi-Fi Auto Switch Utility : Enabling users to quickly access faster network speeds via wired LAN.For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-ToolsThe IT Pro's Choice Since 1985StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales.DK30C2DPPDUE is backed by a StarTech.com 3-year warranty and free lifetime technical support.The StarTech.com Advantage
Logistics data
Harmonized System (HS) code
84733020
Master (outer) case height
25 cm
Master (outer) case length
50 cm
Master (outer) case width
29.5 cm
Products per master (outer) case
6 pc(s)
Network
10G support
No
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Full duplex
Yes
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Operational conditions
Operating relative humidity (H-H)
0 - 95 %
Operating temperature (T-T)
0 - 50 �C
Storage temperature (T-T)
-20 - 70 �C
Other features
Chipset
DisplayLink - DL6950, Genesys Logic - GL3523, Fresco Logic - FL7102, Fresco Logic - FL7201, VIA Labs - VL160, RealTek - RTL8153, Texas Instruments - TS3A225E
Package dimensions
Depth (package,cm)
27 cm
Gross Weight (Package, kg)
0.36 kg
Height (package,cm)
10.5 cm
Width (package,cm)
16 cm
Packaging content
AC adapter included
Yes
Cables included
USB Type-A to USB Type-C
Quick start guide
Yes
Performance
Cable lock slot
Yes
Card reader integrated
No
Certification
CE, FCC, REACH
Data transfer rate
5 Gbit/s
Housing material
Plastic
Maximum digital resolution
5120 x 2880 Pixels
Product colour
Black, Grey
UASP support
Yes
Ports & interfaces
Combo headphone/mic port
Yes
Connectivity technology
Wired
DC-in jack
Yes
DisplayPorts quantity
2
HDMI ports quantity
2
Headphone connectivity
3.5 mm
Headphone outputs
1
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB Power Delivery
Yes
USB Power Delivery up to
60 Watt
Power
AC input voltage
100 - 240 V
Compatible power plug types
EU, UK
Input current
2.5 A
Output current
6.75 A
Output voltage
20 V
Power consumption (typical)
135 Watt
Power plug type
Type N
Product dimensions
Net Weight (Product, kg)
0.28 kg
Product Depth
22 cm
Product Height
3 cm
Product Width
8 cm
Software
Mac compatibility
Yes
Mac operating systems supported
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 13.0 Ventura
Other operating systems supported
ChromeOS
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 95
Sustainability
Sustainability certificates
RoHS
Vendor information
Brand Name
StarTech.com
Warranty
1 Year(s)
