Startech.Com
StarTech.com DK30CH2DEPUE Usb-C Dock - 4K Triple DK30CH2DEPUE
- UPC:
- 0000000000000
- MPN:
- DK30CH2DEPUE
- Condition:
- New
- Availability:
- Available to Order: 3 - 4 weeks leadtime
Description
Laptop Docking Station | Mac, Windows� & ChromeOS� | 2x 4K 60Hz DP + HDMIThis triple-4K dock for Mac, Windows and Chrome USB-C laptops helps you take productivity to a whole new level. With three 4K video connections, 100W Power Delivery, and 5x USB 3.0 ports, the USB-C dock is perfect for your MacBook, Dell XPS, Chromebook or other USB-C laptop requiring additional ports.You can also connect the dock to your USB 3.0 laptop through a USB-A port, using a USB-C to A cable, such as the USB315AC1M(sold separately). Note: Power Delivery to charge your laptop is not available through USB-A, and only dual display is supported.Enhance ProductivityThe 4K USB-C docking station lets you create a three-monitor Ultra HD workstation. Connect:� 2x 4K DisplayPort (DisplayLink) at 4096 x 2160 resolution @ 60Hz / 3840 x 2160 @ 60Hz and� 1x 4K HDMI (DP Alt Mode) at 4096 x 2160 resolution @ 24Hz / 3840 x 2160 @ 30HzFor high-resolution applications, you can connect the dock to a 5K display at 60Hz, using the two DisplayPort ports.100W Power DeliveryUsing a single cable, the USB-C dock will power and charge power-hungry laptops, with up to 100W Power Delivery, and power your peripherals with its 150W power adapter.Powerful ConnectionsThis triple-monitor docking station lets you transform your laptop into a full-sized workstation. It gives you five USB 3.0 ports (1x USB Type-C and 4x USB Type-A incl. 1x Fast-Charge port), a Gigabit Ethernet port, headset jack, and separate 3.5 mm audio and microphone ports.Enhance Productivity and Device Management with the StarTech.com Connectivity Tools ApplicationDeveloped to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:�Advanced Windows Layout Utility : To setup and save custom windows layouts.�Mac Address Pass-Through Utility : To improve network security.�USB Event Monitoring Utility : To track and log connected USB devices�Wi-Fi Auto Switch Utility : Enabling users to quickly access faster network speeds via wired LAN.For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-ToolsThe TAA compliant DK30CH2DEPUE is backed by a StarTech.com 3-year warranty and free lifetime technical support.The StarTech.com Advantage
Logistics data
Harmonized System (HS) code
84733020
Master (outer) case height
37 cm
Master (outer) case length
37 cm
Master (outer) case width
36.5 cm
Products per master (outer) case
8 pc(s)
Network
Auto MDI/MDI-X
Yes
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10, 100, 1000
Full duplex
Yes
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Operational conditions
Operating relative humidity (H-H)
0 - 70 %
Operating temperature (T-T)
0 - 40 �C
Storage temperature (T-T)
-20 - 60 �C
Other features
Chipset
DisplayLink - DL-6950, Genesys Logic - GL3523, Genesys Logic - GL3523S, Texas Instruments - TPS65982, Parade Technologies - PS176
Package dimensions
Depth (package,cm)
32 cm
Gross Weight (Package, kg)
0.51 kg
Height (package,cm)
8 cm
Width (package,cm)
16 cm
Packaging content
AC adapter included
Yes
Cables included
USB Type-C
Manual
Yes
Performance
Cable lock slot
Yes
Card reader integrated
No
Certification
CE, FCC, TAA, REACH
Data transfer rate
5 Gbit/s
Housing material
Plastic
Maximum digital resolution
5120 x 2880 Pixels
On/off switch
Yes
Product colour
Black, Silver
Rubber feet
Yes
UASP support
Yes
Ports & interfaces
Combo headphone/mic port
Yes
Connectivity technology
Wired
DC-in jack
Yes
DisplayPorts quantity
2
HDMI ports quantity
1
Headphone connectivity
3.5 mm
Headphone outputs
2
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Microphone in
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
2
USB Power Delivery
Yes
USB Power Delivery up to
100 Watt
Power
AC input voltage
100 - 240 V
Compatible power plug types
EU, UK
Input current
2.5 A
Output current
7.5 A
Output voltage
20 V
Power plug type
Type N
Power supply
100 Watt
Product dimensions
Net Weight (Product, kg)
0.39 kg
Product Depth
27 cm
Product Height
3.4 cm
Product Width
8.2 cm
Software
Mac compatibility
Yes
Mac operating systems supported
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura
Other operating systems supported
ChromeOS
Windows operating systems supported
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Sustainability
Sustainability certificates
RoHS
Vendor information
Brand Name
StarTech.com
Warranty
1 Year(s)
