StarTech.com EXTEND-HDMI-4K40C6P1 4K Hdmi Extender Over EXTEND-HDMI-4K40C6P1

4K 30Hz 130ft | 1080p 230ft | IR Extension | Power over CableThis HDMI� Extender over CAT6 lets you transmit a 4K 30Hz HDMI� audio video signal up to 130ft (40m), or 230ft (70m) for 1080p resolutions. This converter kit includes both the transmitter and receiver for a complete end-to-end solution.4K Picture QualityThis HDMI extender supports 7.1ch audio and resolutions of up to 4K at 30Hz (3840 x 2160) over a single CAT6/5e cable. The UHD HDMI Extender supports HDMI 1.4 and 4:4:4 chroma subsampling, which ensures a crystal-clear picture.Simplify your setupWith support for Power over Cable (PoC), only one power, connected to the transmitter, is required to power both units of the transmitter and receiver kit. IR extension, using the included IR Blaster and Receiver, makes controlling a source device from a remote location easy.Easy InstallationThe 4K HDMI Extender over Ethernet cable has an HDMI output on the transmitter unit allowing the solution to be cascaded to other video extenders or for use to a local display. Plug-and-play installation with no additional software or drivers required. The metal housing and built-on mounting brackets allow for professional installation options, ideal for digital signage, boardrooms, and tradeshow applications.EXTEND-HDMI-4K40C6P1 is backed by a 2-year StarTech.com warranty and free lifetime technical support.The StarTech.com Advantage

Features



Audio output channels



7.1 channels


Bandwidth



10.2 Gbit/s


Cable types supported



Cat5e, Cat6


Daisy chain



Yes


HDCP



Yes


HDCP version



1.4


LED indicators



Link, Power


Material



Metal


Maximum refresh rate



60 Hz


Maximum resolution



3840 x 2160 Pixels


Maximum transfer distance



70 m


Product colour



Black


Rack mounting



No


Type



AV transmitter & receiver


Logistics data



Harmonized System (HS) code



85176200


Master (outer) case height



37 cm


Master (outer) case length



42 cm


Master (outer) case width



41 cm


Products per master (outer) case



30 pc(s)


Operational conditions



Operating relative humidity (H-H)



20 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage temperature (T-T)



-20 - 60 �C


Package dimensions



Depth (package,cm)



11.6 cm


Gross Weight (Package, kg)



0.17 kg


Height (package,cm)



7.7 cm


Width (package,cm)



20 cm


Packaging content



AC adapter included



Yes


IR blaster included



Yes


IR receiver included



Yes


Ports & interfaces



Connectivity technology



Wired


DC-in jack



Yes


HDMI in



1


Number of HDMI outputs



2


Remote (IR) input



1


Remote (IR) output



1


RJ-45 input ports



1


RJ-45 output ports



1


Power



AC input voltage



100 - 240 V


External power adapter



Yes


Input current



0.3 A


Operating voltage



12 V


Output current



1 A


Power consumption (typical)



0.1 Watt


Power plug type



Type M


Product dimensions



Net Weight (Product, kg)



0.13 kg


Product Depth



5.7 cm


Product Height



1.7 cm


Product Width



6.9 cm


Technical details



Sustainability certificates



CE, RoHS


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
