StarTech.com MASFP10GBSR MA-SFP-10GB-SR COMPATIBLE SFP+ MASFP10GBSR

10 Gbps | Multi Mode Fiber | LC | 300 m (984 ft) | Lifetime WarrantyThe MASFP10GBSR is a Cisco Meraki MA-SFP-10GB-SR compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki� brand switches and routers. It delivers dependable 10GbE connectivity over fiber cable, for 10GBASE-SR compliant networks, with a maximum distance of up to 300 m (984 ft).Technical Specifications:� Wavelength: 850nm� Maximum Data Transfer Rate: 10 Gbps� Type: Multi Mode Fiber� Connection Type: LC Connector� Maximum Transfer Distance: 300 m (984 ft)� MTBF: 1,967,709 hours� Power Consumption: Less than 1.2 Watts� Digital Diagnostics Monitoring (DDM): YesThis SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.StarTech.com SFPsAll StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.The StarTech.com Advantage

Features



Hot-swap



Yes


Housing material



Aluminium


Mean time between failures (MTBF)



1967709 Hour


Product colour



Silver


Logistics data



Harmonized System (HS) code



85369010


Master (outer) case height



35.5 cm


Master (outer) case length



41 cm


Master (outer) case width



35 cm


Products per master (outer) case



100 pc(s)


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



0 - 70 �C


Storage temperature (T-T)



-40 - 85 �C


Package dimensions



Depth (package,cm)



9.3 cm


Gross Weight (Package, kg)



0.047 kg


Height (package,cm)



3.4 cm


Width (package,cm)



11.7 cm


Packaging data



Number of products included



1 pc(s)


Performance



Digital Diagnostics Monitoring (DDM)



Yes


Duplex system



Full


Fiber optic connector



LC


Interface type



SFP+


Maximum data transfer rate



10000 Mbit/s


Maximum transfer distance



300 m


Multi-mode fiber (MMF) supported



Yes


Networking standards



IEEE 802.3ae


SFP transceiver standard



SR


SFP transceiver type



Fiber optic


Wavelength



850 nm


Wavelength-division multiplexing (WDM)



No


Power



Power consumption (typical)



1.2 Watt


Product dimensions



Net Weight (Product, kg)



0.018 kg


Product Depth



5.4 cm


Product Height



1.26 cm


Product Width



1.39 cm


Technical details



Sustainability certificates



CE, RoHS


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
