StarTech.com MDP2DVIS MDP TO DVI ADAPTER MDP2DVIS

Connect a DVI monitor to a single-mode DisplayPort output from your computerThe MDP2DVIS Mini DisplayPort to DVI Active Adapter (single-link) let's you connect your Mini DisplayPort video source (such as any of your MacBook® or Microsoft® Surface™ Pro devices with mDP) to a DVI-D display, including televisions and Apple Cinema Display HD, eliminating the expense of having to upgrade to a DisplayPort capable monitor.Unlike passive video adapters, this Mini DisplayPort to DVI adapter offers an active conversion for use with any Mini DisplayPort output - ideal for graphics cards that are not capable of outputting multi-mode DP++ signals (e.g. ATI Eyefinity).Supporting resolutions up to 1920x1200, this compact device provides a simple solution for adapting PC or Mac® Mini-DisplayPort output for DVI monitors, televisions or projectors.The Mini DP to DVI adapter is compatible with Intel® Thunderbolt™, when connected directly to a supporting DisplayPort over Thunderbolt™ I/O port.Backed by a StarTech.com 3-year warranty and free lifetime technical support.The StarTech.com Advantage

Features



Cable length



0.12 m


Certification



CE, FCC, REACH


Connector 1



Mini DisplayPort


Connector 1 form factor



Straight


Connector 1 gender



Male


Connector 2



DVI-D


Connector 2 form factor



Straight


Connector 2 gender



Female


Converter type



Active video converter


DisplayPort version



1.2


Dual Link DVI



No


HDCP



Yes


HDCP version



1.3


Jacket material



Low smoke zero halogen (LSZH)


Maximum refresh rate



60 Hz


Maximum resolution



1920 x 1200 Pixels


Plug and Play



Yes


Product colour



Black


RoHS compliance



Yes


Logistics data



Harmonized System (HS) code



84733080


Master (outer) case height



22 cm


Master (outer) case length



33.9 cm


Master (outer) case width



49.5 cm


Products per master (outer) case



90 pc(s)


Operational conditions



Operating temperature (T-T)



0 - 70 °C


Storage temperature (T-T)



0 - 70 °C


Package dimensions



Depth (package,cm)



20.7 cm


Gross Weight (Package, kg)



0.036 kg


Height (package,cm)



2.3 cm


Width (package,cm)



10 cm


Packaging data



Quantity per pack



1 pc(s)


Product dimensions



Net Weight (Product, kg)



0.01 kg


Product Depth



20 cm


Product Height



2 cm


Product Width



4.4 cm


Sustainability



Sustainability certificates



CE, RoHS


Technical details



Harmonized System (HS) code



84733080


Sustainability certificates



RoHS


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
