StarTech.com POEINJ1G90W Industrial Gigabit Poe POEINJ1G90W

Rugged PoE Injector | 90 Watts Max | IP-30 Aluminum Housing | 52V-56V DCThis Gigabit Power over Ethernet (PoE+) injector supplies power and data connectivity to a Gigabit PoE-compliant device using a standard Ethernet cable.Flexible Configurations for a Variety of ApplicationsCompatible with IEEE 802.3bt and most previous 90W proprietary PoE (Ethernet) standards, including PoH (HDBaseT), Cisco uPoE, Bosch, and AXIS. One product can cover multiple use requirements to improve standardization and deployment and dual power terminal block inputs provide redundancy for critical applications.90 Watt Power BudgetAs many typical PoE-enabled switches max out at 30W a high 90W power budget is perfect for demanding Type 3 and Type 4 PoE applications like tilt and pan cameras and high power IEEE 802.11ax wireless access points.Designed for Harsh EnvironmentsIndustrial features include -40 C to 75 C operating temperature, IP-30 rated housing, vibration, shock, and free-fall standard testing.• Vibration: EN 60068-2-6• Shock: EN 60068-2-27• Free-fall: EN 60068-2-32500,000+ hours MTBF rating using Telcordia/Bellcore at 50C for long-term reliability.The POEINJ1G90W is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage

Design



Certification



CE, FCC, UL


Housing material



Aluminium


LED indicators



Y, Yes


Product colour



Black


Logistics data



Harmonized System (HS) code



85176990


Master (outer) case height



22.5 cm


Master (outer) case length



34.5 cm


Master (outer) case width



35.5 cm


Products per master (outer) case



10 pc(s)


Management features



Supported network protocols (IPv4)



CSMA/CD


Network



Networking standards



IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u


Operational conditions



Operating relative humidity (H-H)



5 - 95 %


Operating temperature (T-T)



-40 - 75 °C


Storage temperature (T-T)



-40 - 85 °C


Package dimensions



Depth (package,cm)



16.2 cm


Gross Weight (Package, kg)



0.22 kg


Height (package,cm)



6.4 cm


Width (package,cm)



21.1 cm


Packaging content



Quick start guide



Yes


Performance



Auto MDIX IEEE



Yes


Auto-negotiation



Yes


Chipset



Microsemi PD69204


Data transfer rate



1000 Mbit/s


Duplex system



Full


Ethernet LAN data rates



10, 100, 1000


International Protection (IP) code



IP30


Jumbo frames support



Yes


Maximum transfer distance



100 m


Mean time between failures (MTBF)



540891 Hour


Type



Network repeater


Ports & interfaces



Power over Ethernet (PoE) ports quantity



2


Terminal block port



Yes


Power



Power over Ethernet (PoE)



Yes


Power over Ethernet (PoE) voltage range



48 - 56 V


Power plug type



Type N


Total Power over Ethernet (PoE) budget



90 Watt


Product dimensions



Net Weight (Product, kg)



0.17 kg


Product Depth



8.2 cm


Product Height



10.4 cm


Product Width



3.2 cm


Technical details



Sustainability certificates



CE, RoHS


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
