StarTech.com ST12MHDLAN2K Hdmi Over Ip Extender Kit ST12MHDLAN2K

HDMI� Video over Cat5e or Cat6 |Multiple Sources to Multiple Displays | Mobile Control AppThis HDMI over IP extender kit distributes video to a remote location, over your local area network (LAN) and Cat5e or Cat6 Ethernet cabling. By combining this kit with additional receivers (sold separately) and an Ethernet switch (sold separately) you can distribute an HDMI source to multiple locations and create video walls using several remote displays and receivers in the same location.You can also use multiple transmitters on the same network to distribute different video sources or connect the transmitter directly to a receiver at up to 330 ft. (100 m), in a point-to-point setup. Remote control of serial devices is supported through RS-232 extension.Resolutions up to 1080p, with AudioWith support for video resolutions up to 1080p (1920 x 1080 at 60Hz), the transmitter also supports digital and analog audio to the receiver and analog audio from the receiver to the transmitter.Mobile Control Through a Free AppThe kit includes an easy-to-use online app to manage your IP video distribution.The app is available on iOS for an iPhone or iPad, and Android for a smartphone or tablet.Download the StarTech.com Video Control software to manage your IP video distribution.NOTE: Your router must support IGMP snooping. Please refer to your network switch or router documentation to ensure IGMP snooping is supported and enabled.Hassle-Free InstallationsThe HDMI transmitter/receiver kit includes optional shelf-mounting hardware. It uses Cat5e or Cat6 cables and works with existing network infrastructures, eliminating the expense of running proprietary cables.ST12MHDLAN2K is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage

Features



Audio output channels



7.1 channels


Cable types supported



Cat5e, Cat6


Daisy chain



Yes


LED indicators



Link, Network, Power, Status


Maximum refresh rate



60 Hz


Maximum resolution



1920 x 1080 Pixels


Maximum transfer distance



100 m


Product colour



Black


Rack mounting



Yes


Rubber feet



Yes


Supported graphics resolutions



1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800, 1360 x 768 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)


Supported video modes



720p, 1080p


Type



AV transmitter & receiver


Logistics data



Master (outer) case height



27 cm


Master (outer) case length



39 cm


Master (outer) case width



38.5 cm


Products per master (outer) case



6 pc(s)


Operational conditions



Operating relative humidity (H-H)



0 - 80 %


Operating temperature (T-T)



0 - 40 �C


Storage temperature (T-T)



-10 - 60 �C


Package dimensions



Depth (package,cm)



36.5 cm


Gross Weight (Package, kg)



0.59 kg


Height (package,cm)



7.5 cm


Width (package,cm)



23.5 cm


Packaging content



AC adapter included



Yes


Cables included



LAN (RJ-45), Phone (RJ-11)


Included power plug types



ANZ, EU, JP, NA, UK, US


IR blaster included



Yes


IR receiver included



Yes


Manual



Yes


Mounting kit



Yes


Ports & interfaces



3.5 mm (1/8-inch) in



Yes


3.5 mm (1/8-inch) out



Yes


Audio input



2 x 3.5 mm


Audio output



2 x 3.5 mm


HDMI in



1


Number of HDMI outputs



1


RJ-11 ports quantity



4


RJ-45 input ports



1


RJ-45 output ports



1


Power



AC input voltage



100 - 240 V


External power adapter



Yes


Input current



0.6 A


Operating voltage



12 V


Output current



1.5 A


Power consumption (typical)



10 Watt


Power plug type



Type M


Product dimensions



Net Weight (Product, kg)



0.45 kg


Product Depth



0.37 cm


Product Height



0.08 cm


Product Width



0.24 cm


Technical details



Sustainability certificates



CE, RoHS


Sustainability compliance



Yes


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
