StarTech.com SV231DVIUA 2 PORT DVI USB KVM SWITCH SV231DVIUA

Share keyboard, mouse, speakers and a DVI display between two multimedia computers

The SV231DVIUA 2-Port DVI USB KVM Switch lets you control two USB-enabled, DVI-capable computers from a single monitor and peripheral set (keyboard, mouse and speakers), and two additional USB peripherals connected through the built-in USB hub ports.

Featuring convenient hot-key and front panel push-button switching, and high-resolution support (up to 1920x1200), the DVI KVM Switch is perfect for controlling high-performance systems. Ideal for multimedia applications, this KVM switch supports audio and microphone switching either independently, or simultaneously when switching between computers for KVM control.

The DVI USB KVM also features an integrated USB 2.0 hub, which lets you share USB peripherals point as if they were connected directly to the slave computers.

This product is TAA compliant and is backed by a Startech.com 3 year warranty with lifetine technical support.

The StarTech.com Advantage

- Integrated USB 2.0 hub and Mic/Audio ports allow the user to have full multimedia control of two computers and share USB peripherals eliminating the expense of duplicate devices
- High resolution support (1920x1200) offers crystal clear video clarity even on large displays
- Absolutely no software or drivers required, providing a completely OS independent KVM solution

Design



LED indicators



Y, Yes


Mean time between failures (MTBF)



126397 Hour


Product colour



Black


Rack mounting



No


Display



Built-in display



No


Logistics data



Harmonized System (HS) code



85176200


Master (outer) case height



26 cm


Master (outer) case length



39.9 cm


Master (outer) case width



31.4 cm


Products per master (outer) case



6 pc(s)


Operational conditions



Operating relative humidity (H-H)



0 - 80 %


Operating temperature (T-T)



0 - 40 �C


Storage temperature (T-T)



-20 - 60 �C


Package dimensions



Depth (package,cm)



18.7 cm


Gross Weight (Package, kg)



1 kg


Height (package,cm)



9.1 cm


Width (package,cm)



24.2 cm


Packaging content



Manual



Yes


Rubber feet



Yes


Performance



Daisy chain



No


HD type



Full HD


Maximum resolution



1920 x 1200 Pixels


Number of users



1 user(s)


Ports & interfaces



Audio connections



Yes


Console ports



3.5mm headphone, 3.5mm mic, DVI-I, USB A


Console USB ports quantity



4


DC-in jack



Yes


Headphone outputs



3


Keyboard port type



USB


Mouse port type



USB


Number of computers controlled



2


Number of microphone inputs



3


Video port type



DVI-I


Power



AC input voltage



100 - 240 V


Compatible power plug types



EU, UK, US


Input current



0.8 A


Output current



1.5 A


Output voltage



12 V


Power consumption (typical)



18 Watt


Power plug type



Type M


Product dimensions



Net Weight (Product, kg)



0.26 kg


Product Depth



16 cm


Product Height



4 cm


Product Width



19.9 cm


Sustainability



Sustainability certificates



CE, RoHS


Vendor information



Brand Name


StarTech.com


Warranty



1 Year(s)
