ThermalTake PS-TPD-0750F3FAGE-1 Power Supply Unit 750 W PS-TPD-0750F3FAGE-1

Toughpower GF1 ARGB 750W Gold � TT Premium Edition
Toughpower GF1 ARGB Gold Series (650W/750W/850W) is crafted by using cutting-edge technology and materials to become the fusion of aesthetics and performance. The patented 16.8 million-color Riing Duo 14 RGB fan with 18 LEDs preinstalled helps deliver brighter and stunning light effect. The meticulously designed ARGB side panels enable the light to glow through. The series supports synchronization with compatible RGB motherboards from ASUS, GIGABYTE, MSI, and ASRock for countless illumination possibilities. With the most stable but silent operation, the Toughpower GF1 ARGB Gold meets and even exceeds the demanding specification of the overclocker or enthusiastic PC user.

Shining from Perfect Circles
Show off the fascinating illumination through the unique ARGB side cover design and add the amazing effect on your build.

Sync with Motherboard ARGB Software
To reach endless lighting customization, the Toughpower GF1 ARGB supports motherboards with a 5V addressable RGB header from ASUS, GIGABYTE, MSI, and ASRock. Users get to control the lights directly from the software released by those brands without enabling any additional lighting software or controllers. For more details, please visit ASUS, GIGABYTE, MSI and ASRock official websites.

Zero Cable Platform
Farewell to messy cables! The daughterboards are directly soldered to the motherboard for better heat dissipation and impressive output power quality

Zero Cable Platform
Farewell to messy cables! The daughterboards are directly soldered to the motherboard for better heat dissipation and impressive output power quality

< 30 mV Low Ripple Noise
All ripples are lower than 30mV on +12V, +5V, or +3.3V from 0% to 100% load to ensure an excellent performance and a reliable operation.

Extremely Strict Voltage Regulation < �2%
The voltage regulation, more strict than Intel�s standard �5% for major rails and �10% for -12V, is set to no more than �2% for major rails to meet the highest performance.

100% High Quality Japanese 105�C/221�F Capacitors
Comes with high quality 105 �C (221 � F) Japanese capacitors to help improve the durability and offer impressive stability.

Fully Modular Low-profile Flat Black Cables
The series offers cable selection for users while powering the system at an advantageous voltage. The low-profile flat black cables make cable management easier, reduce clutter and increase airflow inside the chassis.

Fully Modular Low-profile Flat Black Cables
The series offers cable selection for users while powering the system at an advantageous voltage. The low-profile flat black cables make cable management easier, reduce clutter and increase airflow inside the chassis.

80 PLUS Gold Certified and Intel C6/C7 States Ready
Saves energy through its high energy efficiency up to 90% and is certified to 80 PLUS� Gold. The series has been optimized to work with all generations of Intel�s processors to achieve maximum energy saving.

Design



Cooling type



Active


Illumination



Yes


Number of fans



1 fan(s)


On/off switch



Yes


Product colour



Black


Logistics data



Harmonized System (HS) code



84733020


Operational conditions



Operating temperature (T-T)



0 - 50 �C


Storage relative humidity (H-H)



20 - 90 %


Package dimensions



Gross Weight (Package, kg)



0.65 kg


Performance



80 PLUS certification



80 PLUS Gold


Mean time between failures (MTBF)



120000 Hour


Power supply unit (PSU) form factor



ATX


Purpose



PC


Ports & interfaces



ATX Power connector (24-pin)



Yes


Floppy disk drive connector



Yes


Floppy drive power connector



1


Motherboard power cable length



60 cm


Motherboard power connector



24-pin ATX


Number of SATA power connectors



9


PCI Express connector



Yes


PCI Express power connectors (6+2 pin)



4


Peripheral (Molex) power cable length



150, 500


Peripheral (Molex) power connectors (4-pin)



4


SATA power cable length



150, 500


Power



AC input frequency



50 - 60 Hz


AC input voltage



100 - 240 V


Combined power (+12V)



750 Watt


Combined power (+3.3V)



120 Watt


Combined power (+5Vsb)



15 Watt


Combined power (-12V)



3.6 Watt


Input current



10 A


Max output current (+12V)



62.5 A


Max output current (+3.3V)



120 A


Max output current (+5V)



22 A


Max output current (+5Vsb)



3 A


Max output current (-12V)



0.3 A


Peak power



900 Watt


Power Factor Correction (PFC) type



Active


Power protection features



Over current, Over power, Over voltage, Short circuit


Total power



750 Watt


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



16 cm


Product Height



8.6 cm


Product Width



15 cm


Vendor information



Brand Name


ThermalTake


Warranty



1 Year(s)
