Toshiba MK7575GSX-RFB 750GB 5400RPM 8MB 9.5MM SATA MK7575GSX-RFB

- 160 to 750 GByte capacity
- 4kB sector size
- 9.5 mm height
- 3.0 Gbps max. SATA II interface
- 400 G max. operating shock
- 900 G max. non-operating shock
- 8 MByte buffer

Product info
With the MKxx75GSX Toshiba supports the demand for high capacity extremely compact mobile storage.
Featuring a profile of only 9.5mm, the two-platter drive series is ideal for integration into premium notebooks, high-end PCs and portable external hard disk drives. This product family offers up to 750GB capacity and a rotational speed of 5,400RPM. In addition, the series, including the powerful self-diagnostic capability making it very reliable, also provides a market-leading areal density of 555.1Gbit/in�. This extends its possible uses from high end personal computing and data storage into the set-top box and Personal Video Recorder segments.
The environmental friendly MKxx75GSX series features an Advanced Sector Format Technology, which uses 4K byte-per-sector formatting and improved error-correcting code functions to provide maximum error detection and more efficient use of the storage surface area.

Features



Average seek time



12 Millisecond


Bytes per sector



512


HDD capacity



750 GB


HDD number of heads



4


HDD size



2.5 "


HDD speed



5400 RPM


Interface



Serial ATA II


Mean time between failures (MTBF)



600000 Hour


SMART technology



Yes


Storage drive buffer size



8 MB


Track to track seek time



2 Millisecond


Operational conditions



Non-operating altitude



-300 - 12000 m


Non-operating shock



900 G


Non-operating vibration



5 G


Operating altitude



-300 - 3000 m


Operating relative humidity (H-H)



8 - 90 %


Operating shock



400 G


Operating temperature (T-T)



5 - 55 �C


Operating vibration



1 G


Storage relative humidity (H-H)



8 - 90 %


Storage temperature (T-T)



-40 - 60 �C


Other features



Data transfer rate



3 Gbit/s


Internal



Yes


Mounting



Horizontal


USB powered



No


Package dimensions



Gross Weight (Package, kg)



0.1 kg


Power



Operating voltage



5 V


Power consumption (idle)



0.15 Watt


Power consumption (read)



1.5 Watt


Power consumption (standby)



0.18 Watt


Power consumption (typical)



4.5 Watt


Power consumption (write)



1.5 Watt


Product dimensions



Net Weight (Product, kg)



0.09000000000000001 kg


Product Depth



10 cm


Product Height



0.95 cm


Product Width



6.98 cm


Vendor information



Brand Name


Toshiba


Warranty



1 Year(s)
