TP-Link RE600X Ax1800 Wi-Fi 6 Range Extender RE600X

Boosted WiFi Coverage for Ultimate Wireless Experience
AX1800 WiFi 6 Range Extender

Meet the next generation WiFi 6 with more capacity and data throughput
With WiFi 6, you will enjoy faster speeds, lower latency, and able to connect more devices. When comparing with the last-gen WiFi, WiFi 6 features 25% faster data throughput thanks to 1024-QAM.

Roaming Redefined
Stop searching around for full bars. OneMesh is a simple way to form a Mesh network with a single WiFi name for seamless whole-home coverage. Just connect RE600X to an OneMesh router.

Increased Efficiency with OFDMA
OFDMA improves your wireless network with higher throughput, lower latency, and more efficient power consumption.

Boosted WiFi Coverage with Beamforming
Beamforming technology concentrates the WiFi signal towards your connected devices, providing better WiFi range and network performance.

Gigabit Ethernet for Reliable Connections
One Gigabit Ethernet port provides warp-speed wired connections for 4K HD streaming, lag-free gaming, and more.

Built-In Access Point Mode
RE600X is more than a wireless range extender. Simply plug an Ethernet cable into its Ethernet port, and easily turn your wired internet connection into a 2×2 MIMO dual band wireless access point.

Wide. Wider. Widest.4
You can set the extender’s WiFi coverage depending on how large you want your WiFi area to be using the Tether app.

Control at Your Fingertips
Set up and manage your WiFi through the TP-Link Tether app from your phone (Android, iOS), including TP-Link routers and range extenders.

Antenna



Antenna type



Internal


Antennas quantity



2


Transmitting power (CE)



2.4 GHz ≤20dBm, 5 GHz ≤30dBm dBm


Design



Certification



FCC, RoHS


LED indicators



Y, Yes


Product colour



White


Quantity per pack



1 pc(s)


Reset button



Yes


Logistics data



Harmonized System (HS) code



85176990


Network



Cabling technology



10/100/1000Base-T(X)


Networking standards



IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n


Security algorithms



WEP, WPA, WPA2, WPA3


Wi-Fi



Yes


Wi-Fi band



Dual-band (2.4 GHz / 5 GHz)


Wi-Fi data rate (max)



1200 Mbit/s


Wi-Fi standards



802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Storage relative humidity (H-H)



5 - 90 %


Package dimensions



Depth (package,cm)



12.5 cm


Gross Weight (Package, kg)



0.52 kg


Height (package,cm)



9.7 cm


Width (package,cm)



20.2 cm


Packaging content



Quick start guide



Yes


Performance



BeamForming



Yes


Browser supported



Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0


Data transfer rate



1201 Mbit/s


Ethernet LAN data rates



10, 100, 1000


Linux operating systems supported



Y, Yes


Mac compatibility



Yes


Mac operating systems supported



Yes


Windows operating systems supported



Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP


WPS push button



Yes


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Power



AC input frequency



50/60 Hz


AC input voltage



100 - 240 V


Power consumption (max)



10 Watt


Power consumption (typical)



10.8 Watt


Product dimensions



Net Weight (Product, kg)



0.4 kg


Product Depth



3.6 cm


Product Height



14.9 cm


Product Width



7.8 cm


Technical details



Sustainability certificates



CE, Federal Communications Commission (FCC), RoHS


Vendor information



Brand Name


TP-Link


Warranty



1 Year(s)
