TP-Link RE605X Ax1800 Wi-Fi Range Extender RE605X

Expand Your Ultimate WiFi Experience
AX1800 WiFi 6 Range Extender

Get More Range with Your Existing Router
A single router has limited WiFi coverage and always causes WiFi dead zones. RE605X wirelessly connects to your existing router and boosts more WiFi signals throughout your home, allowing you to enjoy smooth WiFi 6 network experiences everywhere with great speed, capacity, and coverage.

WiFi 6: More Connections with Better Performance
The latest Wi-Fi 6 technology is built for today�s devices, eliminating lag, endless loading, and dead spots. It fully satisfies your network needs especially for bandwidth-intensive tasks like cloud gaming or 4K UHD video.

TP-Link OneMesh:Optimize for Smoothest WiFi Experience
OneMesh� is a simple way to form a Mesh network with a single WiFi name for seamless whole home coverage. Just connect a OneMesh� range extender to a OneMesh� router. No more searching around for a stable connection.

Enjoy an AX Mesh Network with Your Existing Router
Want a Mesh network? Hesitating whether you should replace your current router with a new Mesh set?

Built-In Access Point Mode
RE605X is more than a wireless range extender. Simply plug an Ethernet cable into its Ethernet port, and easily turn your wired internet connection into a 2�2 MU-MIMO dual band wireless access point.

Control at Your Fingertips
Set up and manage your Wi-Fi through the TP-Link Tether app from your smartphone (Android, iOS), including TP-Link routers and range extenders.

Antenna



Antenna type



External


Antennas quantity



2


Transmitting power (CE)



2.4 GHz ?15dBm, 5 GHz ?21dBm dBm


Design



LED indicators



Y, Yes


Product colour



White


Quantity per pack



1 pc(s)


Reset button



Yes


Logistics data



Harmonized System (HS) code



85176990


Network



Cabling technology



10/100/1000Base-T(X)


Networking standards



IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n


Security algorithms



64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK


Wi-Fi



Yes


Wi-Fi band



Dual-band (2.4 GHz / 5 GHz)


Wi-Fi data rate (max)



1200 Mbit/s


Wi-Fi standards



802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)


Operational conditions



Operating relative humidity (H-H)



10 - 90 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



5 - 90 %


Storage temperature (T-T)



-40 - 70 �C


Package dimensions



Depth (package,cm)



12.5 cm


Gross Weight (Package, kg)



0.29 kg


Height (package,cm)



9.7 cm


Width (package,cm)



20.2 cm


Packaging content



Manual



Yes


Quick start guide



Yes


Performance



Browser supported



Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0


Data transfer rate



1201 Mbit/s


Ethernet LAN data rates



10, 100, 1000


Linux operating systems supported



Y, Yes


Mac operating systems supported



Yes


Type



Network repeater


Windows operating systems supported



Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP


WPS push button



Yes


Ports & interfaces



Ethernet LAN (RJ-45) ports



1


Power



AC input frequency



50/60 Hz


AC input voltage



100 - 240 V


Power consumption (typical)



10 Watt


Product dimensions



Net Weight (Product, kg)



0.22 kg


Product Depth



4.6 cm


Product Height



12.48 cm


Product Width



7.4 cm


Technical details



Commodity Classification Automated Tracking System (CCATS)



85183095


Sustainability certificates



CE, RoHS


Vendor information



Brand Name


TP-Link


Warranty



1 Year(s)
