Tp-Link TL-SG116P 16-Port Gigabit Desktop Switch With 16-Port Poe+ TL-SG116P

16-Port Gigabit Desktop Switch with 16-Port PoE+

16x 10/100/1000 Mbps RJ45 ports
With 16 PoE+ ports, transfers data and power on one single cable
Compliance with IEEE 802.3af/at PoE+, the switch supports PoE Power up to 30 W for each PoE port
Supports PoE Power up to 120 W for all PoE ports*
Up to 250 m data and power transmission range under Extend Mode**
Priority Mode ensures high priority of ports 1–4 to guarantee the quality of the sensitive applications
Isolation Mode allows one-click client traffic separation for higher security and performance
Automatically reboots your dropped or unresponsive PoE-powered devices with PoE Auto Recovery
Plug and play with no configuration required



*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.

**The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.

DescriptionSpecification

Rackmountable: No
Managed: No
Number of Ports: 16
RJ45 Data Transfer Rate: 10/100/1000 Mbps
Interface(s): 16 x 10/100/1000Mbps RJ45 Ports
AUTO Negotiation
AUTO MDI/MDIX
PoE Ports (RJ45): Standard: 802.3 af/at compliant
PoE Ports: Ports 1–16
Power Supply: 120 W
Switching Capacity: 32 Gbps
Power Supply: External Power Adapter (Output: 53.5 VDC / 2.43 A)
Dimensions: (WxDxH) 286 x 111.7 x 25.4 mm
Transfer Method: Store-And-Forward
Mac Address Table: "8K, Auto-learning, Auto-aging"
Packet Forwarding Rate: 23.8 Mpps
Advanced Functions: "Compatible With IEEE 802.3af/at Compliant PDs
Extend Mode Button (Ports 1–4, Up to 250m PoE power & data transmission)
Priority Mode Button (Ports 1–4)
Isolation Mode Button (Ports 1–7 / 8-14)
PoE Auto Recovery (Ports 1-16)
Mac Address Auto-Learning And Auto-Aging
IEEE 802.3x Flow Control
IGMP Snooping"
Quality of Service: 802.1p/DSCP QoS
Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing
Package Contents: TL-SG116P
Power Adapter
Installation Guide
Package Type: Retail
Package Weight: To be confirmed
Warranty: Limited Lifetime
