Vertiv GXT5-3000IRT2UXL Vertiv Liebert GXT5 1ph UPS. GXT5-3000IRT2UXL

The Vertiv� Liebert� GXT5 UPS 3000VA/3000W, is a 2U UPS solution for ensuring the health and availability of IT infrastructure. With online, double conversion technology, the UPS protects critical equipment against outages and every type of power disturbance. This can support a wide range of power environment including 200/208/220/230/240V user configurable AC power and has scalable runtime options with matching external battery cabinets to offer extra time during an outage.

- PREMIUM POWER PROTECTION: It offers reliable, easy-to-manage power protection and battery backup with 1500VA (1500W) capacity.
- UNITY POWER FACTOR (1.0): This online UPS has more usable power, which allows more connected loads to save space and costs.
- 4 PROGRAMMABLE RECEPTACLES: It includes four individual programmable output receptacles for device control and optimum battery usage.
- ENERGY EFFICIENT: It is ENERGY STAR 2.0 certified with higher efficiency, for energy savings and improved reliability.
- EASY-TO-USE INTERFACE: It has a tower/rack mount design with gravity sensing feature and color graphic display.

The Vertiv� Liebert� GXT5 UPS is an online double conversion UPS solution which offers premium power outage protection and continuous power conditioning in a compact and flexible deployment system. It protects critical equipment against outages and every type of power disturbance without drawing on battery power, which extends battery life and minimizes replacements. This single-phase UPS operates with high power efficiency is intended for both centralized and edge applications. The unit includes a rack mounting hardware kit and base for tower installation in open environments. Scalable runtime options with matching external battery cabinets and hot-swappable internal batteries offer additional flexibility when extended uninterrupted power is required. Standard models include Liebert� RDU101, a network management card with security and remote management capabilities that makes systems easy to deploy and simple to manage. With optional Vertiv� LIFE� Services, data center managers can reduce the risk of unexpected downtime through remote diagnostic and preventive monitoring.

Benefits
- More usable power to support more connected loads for cost and space savings
- Simplified installation and operation
- Remote UPS firmware upgrade capability
- Ability to prioritize critical loads
- Improved ability to manage connected devices without impacting continuity
- Streamlined remote monitoring and operational efficiency
- Faster deployment and accurate runtime information
- Intelligent battery health management for optimized service life
- Optimized energy and capacity management
- Eligible for the Vertiv� Trade-In Program. Contact a Vertiv partner for discount rates and to calculate your savings

Battery



Battery capacity



9 VAh


Battery recharge time



3 Hour


Battery technology



Sealed Lead Acid (VRLA)


Battery voltage



12 V


Hot-swap battery



Yes


Typical backup time at full load



3.3 min


Typical backup time at half load



10.8 min


Design



Certification



IEC/EN/AS 62040-2 2nd Ed (Cat 2 � 6); FCC 15 A CISPR22 A(RFI)


Control type



Buttons


Display type



LCD


Form factor



Rackmount/Tower


International Protection (IP) code



IP20


LED indicators



Y, Yes


Product colour



Black


Rack capacity



2U


Safety



EN 62040-1:2008+A1:2013


Features



Audible alarm(s)



Yes


ECO mode



Yes


Efficiency



95 %


Efficiency (ECO mode)



98 %


Efficiency (On-line mode)



95 %


Emergency Power Off (EPO)



Yes


Input frequency



40 - 70 Hz


Input operation voltage (max)



288 V


Input operation voltage (min)



115 V


Input power factor



0.99


Noise level



48 dB


Number of input phases



1


Number of output phases



1


Output frequency



50/60 Hz


Output operation voltage (max)



240 V


Output operation voltage (min)



200 V


Output power



3000 Watt


Output power capacity



3 kVA


Output voltage regulation



�3 %


Power factor



1


Power protection features



Overload


Surge protection



Yes


UPS topology



Double-conversion (Online)


Waveform



Sine


Logistics data



Harmonized System (HS) code



85078000


Operational conditions



Operating altitude



0 - 3000 m


Operating relative humidity (H-H)



0 - 95 %


Operating temperature (T-T)



0 - 40 �C


Storage relative humidity (H-H)



0 - 95 %


Storage temperature (T-T)



-15 - 40 �C


Other features



Battery type



VRLA


Bypass



Yes


Input connection type



C20


Nominal input voltage



230 V


Nominal output voltage



230 V


Non-operating relative humidity (non-condensing)



0 - 95 %


Output connections



IEC320 C13 & C19


Overload protection



Yes


Package dimensions



Depth (package,cm)



61.7 cm


Gross Weight (Package, kg)



33.12 kg


Height (package,cm)



26.2 cm


Width (package,cm)



51.7 cm


Packaging data



Cables included



USB cable


Quick installation guide



Yes


Ports & interfaces



AC outlet types



C13 coupler, C19 coupler


AC outlets quantity



7 AC outlet(s)


Ethernet LAN (RJ-45) ports



1


Modem (RJ-11) ports



1


Power plug



C20 coupler


Serial interface type



RS-232, RS-485


Serial ports quantity



1


USB 2.0 ports quantity



1


USB port



Yes


USB port type



USB Type-B


Product dimensions



Net Weight (Product, kg)



28.2 kg


Product Depth



47 cm


Product Height



8.5 cm


Product Width



43 cm


Technical details



Sustainability certificates



ENERGY STAR, REACH, RoHS, WEEE


Sustainability compliance



Yes


Vendor information



Brand Name


Vertiv


Warranty



2 Year(s)
