Zebra SP7208-SV4U2100TZW SP7208-SV Black USB KIT with SP7208-SV4U2100TZW

EASY TO DEPLOY, HIGH PERFORMANCE, ON-COUNTER SCANNING
When it comes to on-counter scanning, the DS7708 offers a feature set that puts it at the top of its class for performance, ease of deployment and total cost of ownership. No matter what barcodes appear at your POS, the DS7708 can scan them all; 1D, 2D, printed and electronic.

With its compact design, the DS7708 can easily be installed in even the most space constrained checkout lanes. And extraordinary durability minimizes costs and protects uptime, maximizing device lifecycle and your return on investment.

LARGEST FIELD OF VIEW AND OMNI-DIRECTIONAL SCANNING FOR SCANNING SIMPLICITY
A field of view that is over 50 percent larger than competitive 2D imagers enables easy capture of barcodes, regardless of where they are located on an item. Scanning is truly second nature. No need to orient an item to capture the barcode.

IMAGE CAPTURE SUPPORT EXPANDS FUNCTIONALITY AND INCREASES VALUE
The DS7708 offers additional data capture features to further streamline your business processes. Workers can take a picture of a check, driver�s license or I.D. card to meet store requirements or industry regulations in a split second.

PRZM INTELLIGENT IMAGING TECHNOLOGY FOR NEXT GENERATION SCANNING PERFORMANCE
Resets the bar for 2D imaging by improving decode performance and dramatically improving the user experience, user productivity, throughput and customer wait times.

Zebra DS7708 Vertical Slot Scanner

SUPERIOR OUT-OF-BOX EXPERIENCE
Smart auto-host detect cables automatically determine which interface is attached, eliminating the need to scan numerous configuration barcodes. Over 90 international keyboards are supported, enabling easy setup, all around the world.

Logistics data



Harmonized System (HS) code



84716070


Operational conditions



Operating relative humidity (H-H)



20 - 95 %


Operating temperature (T-T)



0 - 50 �C


Storage temperature (T-T)



-40 - 70 �C


Package dimensions



Gross Weight (Package, kg)



1 kg


Packaging data



Cables included



USB


Performance



International Protection (IP) code



IP52


Product colour



Black


Ports & interfaces



Connectivity technology



Wired


Standard interfaces



USB


Power



Input voltage



5 V


Power source type



DC


Product dimensions



Net Weight (Product, kg)



0.5 kg


Product Depth



9.7 cm


Product Height



14.3 cm


Product Width



14.9 cm


Scanning



2D (matrix & stacked) barcodes supported



Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39


Light levels (direct sunlight)



0 - 86100 lx


Linear (1D) barcodes supported



Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar, MSI, Plessey, UPC-A


Optical sensor resolution (W x H)



1920 x 1200 Pixels


Pitch reading angle



-70 - 70 �


Scanner type



1D/2D


Sensor type



LED


Tilt reading angle



0 - 360 �


Type



Built-in bar code reader


Wavelength



660 nm


Yaw reading angle



-70 - 70 �


Technical details



Harmonized System (HS) code



84716070


Vendor information



Brand Name


Zebra


Warranty



3 Year(s)
